Eko Box II pellet boilers are a convenient and environmentally friendly solution. They are very effective in operation and, just as importantly, energy efficient. As a result, the investment in a new central heating boiler is quickly returned. The form in which pellets - solid fuel - are purchased is also convenient. It is available in large bags, it is packaged in 15 kg. The device is equipped with a self-cleaning exchanger, reducing handling to a minimum, and a pellet burner with a movable grate, allowing pellets of 6-8 mm granulation to be burned. The Eko Box II boiler is equipped with systems that allow automatic cleaning of the burner and boiler exchanger.
Pellet boiler
Eko Box II
Compact and modern
The Eko Box II is the ideal choice for users who value convenience and cleanliness in the boiler room. The boiler was built with small and cramped boiler rooms in mind. The design of the boiler with an integrated pellet tank allows it to effectively heat houses with an area of 60 to 230 m2. The pellet heating device is equipped with a self-cleaning burner and a self-cleaning exchanger, which allows the boiler to be used comfortably with minimal maintenance. The built-in pellet tank has a capacity of 120 L to 140 L, depending on the boiler output. Eko Box II is equipped with electronics that allow connecting five heating system pumps and two mixing valves. The electronics can be expanded to control the boiler via the Internet or connect a room controller.
The boiler has dust emissions of less than 20 mg/m3 of flue gases, thanks to which the boiler can receive the highest possible subsidies under the "Clean Air" program.
Eko Box II
Advantages of the boiler
- Warranty
- for the tightness of the exchanger - 60 months
- Automatic
- cleaning the pellet burner
- Automatic
- cleaning of the boiler exchanger
- Exchanger
- boiler made of certified 6 mm boiler steel
- Controller
- supports 5 pumps and 2 mixing valves as standard
Characteristics
Type of boiler: with built-in feeder
Tank: 10 kW - 120 L, 15 kW - 140 L, 20 kW - 140 L
Power available: 10 kW, 15kW, 20 kW
5 emission class: 10 kW, 15kW, 20 kW
Reduced dust emissions of less than 20mg: 10 kW, 15kW, 20 kW
Ecodesign: 10 kW, 15kW, 20 kW
Fuel type: wood pellets 6 - 8 mm
Energy efficiency: A+
Controller: ST 978T
Guarantee: 5 years for exchanger tightness
Standard equipment:
- ST 978T controller supporting 5 pumps, 2 mixing valve actuators and 2 room controllers
- self-cleaning burner
- igniter
- external sensor
Equipment additionally paid:
- WIFI RS module
- room controller ST 281
Boiler data
Eko Box II
| BOILER POWER [kW] | BOILER HEATING AREA [m2] | MAX. HEATING AREA [m2] |
|---|---|---|
| 10 | 1.3 | up to 125 |
| 15 | 1.7 | up to 185 |
| 20 | 2.3 | up to 250 |
Eko Box II
Eko Box II is a pellet boiler that has a number of advantages due to its design and user-friendly controller. First of all, it has compact dimensions, which allows the boiler to be installed in cramped boiler rooms. We provided it with a very convenient and easy-to-use electronic controller, allowing it to operate five pumps and two mixing valves. The controller is equipped with a color touch-screen control panel. With the help of an additional WIFI RS Internet module, it can be synchronized with a cell phone, allowing even more convenient operation of this compact pellet boiler.
